We have a varied range of standard dimensional /capacity of vessel / reactors. Along with this we specialize in producing vessel/reactors as per customized specifications.Every step of automation is beaked with proper drawing approach & pictures.We specialize in Design, Fabrication, Supply, Installation and Testing as per customer’s requirement.
Our experiences team of Engineers can also assist in designing of glass reactor as per your requirement. Feel free to call or mail us at anshul@goelequipments.com for support.
Salient Features
- Glass Reactors made from Germany Raw Material.
- Lab Reactor system suitable for most benchtop fume hoods.
- Stirrer with suitable mechanical seal/stuffing box/magnetic seal.
- Skid Mounted and quick release clamp for easy installation & removable of glassware.
- Suitable for vacuum condition
- Flush bottom with minimum dead volume.
- Overhead Stirrer geared motor with built-in speed controller & display.
- Measurement Marking on the vessel.
- Interchangeable Stirrer anchor, propeller, turbine Digital temperature indicator
Reactor Options
Single Wall, Double Wall or Tripple Wall Glass Reactors
Operating Conditions
Temperature : – 50°C up to 180 °C
Pressure : Full vacuum up to 0.5 bar
Capacities : 100 ml up to 10 L
Optional :
Hot water/oil circulator, Chiller, heating /Cooling system ,Vacuum Pump, PH probe with transmitter, Pressure Gauge.
| Unit Cat. Ref. | Reactor Cap(L) | Gear Motor With Inbuilt Digital Indicator | Addition Funnel | Condenser Length | L x B x H |
|---|---|---|---|---|---|
| LJR 1L | 1 Ltr. (100DN) | Speed 40 – 400 RPM | 250ml | 200mm | 250x250x900 |
| LJR 2L | 2 Ltr. (100DN) | Speed 40 – 400 RPM | 500ml | 300mm | 250x250x1350 |
| LJR 3L | 3 Ltr. (100DN) | Speed 40 – 400 RPM | 500ml | 400mm | 250x250x1450 |
| LJR 5L | 5 Ltr. (150DN) | Speed 40 – 400 RPM | 1000ml | 500mm | 350x350x1450 |
| LJR 10L | 10 Ltr. (200DN) | Speed 40 – 400 RPM | 2000ml | 600mm | 400x400x1700 |
